Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
14.51 m
Specs
Main
| Maker | Delphia Yachts |
| Maker website | https://www.delphiayachts.com |
| Model | Delphia 46 DS - Deep draft |
| First built hull | 2011 |
| Version | Deep draft |
| Price | 240,000 € |
| Boat type | Sail |
| Category | Cruiser BoatsCenter Cockpit Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 14 kmh |
| Mast height | 20.45 m |
| Length overall | 14.51 m |
| Length at waterline | 12.86 m |
| Beam overall | 4.51 m |
| Draft maximum | 2.32 m |
| Displacement | 14,299.94 kg |
| Ballast weight | 4,500.09 kg |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Central cockpit |
Designer
| Naval architect | |
| Name/Studio | Andrzej Skrzat |
Rig & Sails
| Mast | 67.1 |
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 3 |
| Spreaders angle | Swept-back |
| Upwind sail area | 120.22 sq.m |
| Downwind sail area | 153.48 sq.m |
Engine
| Engine A | |
| Power | 100 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.03 |
| Upwind SA to Displacement | 20.75 |
| Downwind SA to Displacement | 26.5 |
| Hull Displacement Speed | 0.03 |
| Displacement to Length (D/L) | 8.7 |
| Ballast to Displacement (B/D) | 0.31 |
| Capsize Screening Formula (CSF) | 1.88 |
