2020 Discovery Yachts Group Southerly 54

1175

0

2020 Discovery Yachts Group Southerly 54
Preview

Boat Overview

  • Type
    sail
  • Maker
    Discovery Yachts Group
  • Hull type
    monohull
  • Hull Material
    composite_material
  • Category
    -
  • Boat length (LOA)
    16.67 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerDiscovery Yachts Group
Maker websitehttps://discoveryshipyard.com/
ModelSoutherly 54
First built hull2020
Last built hull-
Version-
Price940000 EUR
Boat typesail
Category-
Hull typemonohull
Hull materialcomposite_material
Cabins-
Births-
Heads-
General
NameValue
Top speed15.08 kmh
Cruising speed-
Mast height24.44 m
Length overall16.67 m
Length at waterline14.66 m
Beam overall4.82 m
Beam center-line-
Beam hull-
Headroom-
Bridgedeck clearance-
Nominal bridgedeck clearance-
Draft maximum3.35 m
Draft minimum-
Displacement23346.03 kg
Tonnage Gross-
Tonnage Net-
Ballast weight-
Ballast type-
Helm2 wheels
Rudder2 spade rudders
Hull appendages
Hull appendages A-
CockpitCentral cockpit
Unsinkable-
Trailerable-
CE classification
CE classification A-
CE classification B-
CE classification C-
CE classification D-
Designer
NameValue
Naval architect
Name/StudioEdward Dubois
Website-
Exterior designer
Name/Studio-
Website-
Interior designer
Name/Studio-
Website-
Rig & Sails
NameValue
Riggingsloop
Rotating spars-
Mast80.2
SparsMast and boom in Aluminum
Standing rigging-
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area180.04 sq.m
Downwind sail area-
Mainsail
Mainsail A893.00
Headsail
Headsail A-
Spinnaker
Spinnaker A-
Engine
NameValue
Engine A
Maker-
Website-
Model-
TypeInboard engine ; Diesel
Drive-
Fuel-
Power146
Power Typehp
Engine B
Maker-
Website-
Model-
Type-
Drive-
Fuel-
Power-
Power Typehp
Storage
NameValue
Fuel tank
Fuel tank A900.07 liter
Water tank
Water tank A799.77 liter
Holding tank
Holding tank A-
Water heater
Water heater A-

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 10.33
Upwind SA to Displacement22.42
Downwind SA to Displacement-
Hull Displacement Speed 9.29
Displacement to Length (D/L) 206.38
Ballast to Displacement (B/D) -
Capsize Screening Formula (CSF) 1.7
Stability Speed-
Kelsall Stability Index (KSI)-
