Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11.95 m
Specs
Main
Name | Value |
---|---|
Maker | Dufour Yachts |
Maker website | https://www.dufour-yachts.com |
Model | 390 Grand Large - Shoal draft |
First built hull | 2018 |
Version | Shoal draft |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 12.65 kmh |
Length overall | 11.95 m |
Length at waterline | 10.52 m |
Beam overall | 3.99 m |
Draft maximum | 1.77 m |
Displacement | 7,700.18 kg |
Ballast weight | 2,100.13 kg |
Ballast type | Cast iron |
Helm | 2 wheels |
Rudder | 1 spade rudder |
Cockpit | Closing aft cockpit with opening system |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Felci Yacht Design |
Website | https://www.felciyachtdesign.com |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum (carbon fiber as an option) |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 66.52 sq.m |
Mainsail A | 394.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 40 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 17.35 |
Displacement to Length (D/L) | 7.87 |
Ballast to Displacement (B/D) | 0.27 |
Capsize Screening Formula (CSF) | 2.04 |
