Boat Overview

  • Type
    Sail
  • Maker
    Elan Yachts
  • Hull type
    Monohull
  • Hull Material
    Fiberglass
  • Category
    Cruiser Boats, Daysailer Boats
  • Boat length (LOA)
    6.13 m

Boat Description

The Elan E1 has a sleek profile and a beautiful interior, making it one of the most desirable yachts on the market today.

It's designed for comfort and relaxation, with a spacious interior that can accommodate up to six guests.

The Elan E1 offers a unique combination of performance and comfort, with a range of features that make it easy to operate on the water. It has an innovative folding keel design that allows for easy storage and transport. Its foredeck features a large sunbathing area and an integrated swim platform, making it ideal for entertaining guests.

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerElan Yachts
Maker websitehttps://www.elan-yachts.com/
ModelE1
First built hull2015
Price28500 €
Boat typeSail
Category Cruiser Boats, Daysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins2
Births4
Heads1
General
NameValue
Top speed9.67 kmh
Mast height10.39 m
Length overall6.13 m
Length at waterline6.13 m
Beam overall2.50 m
Draft maximum1.55 m
Displacement990.19 kg
Ballast weight360.15 kg
Helm1 tiller
Rudder2 transom hung rudders
CockpitOpen aft cockpit
Trailerable
Designer
NameValue
Naval architect
Name/StudioHumphreys Yacht Design
Websitehttp://www.humphreysdesign.com
Rig & Sails
NameValue
Mast34.1
SparsAluminum spars
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area28.06 sq.m
Downwind sail area68.47 sq.m
Mainsail A178
Headsail A125
Spinnaker A560
Engine
NameValue
Engine A
FuelGas
Power6 HP
TypeOutboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 16.93
Upwind SA to Displacement28.72
Downwind SA to Displacement70.09
Hull Displacement Speed 6.01
Displacement to Length (D/L) 120.01
Ballast to Displacement (B/D) 36.37
Capsize Screening Formula (CSF) 2.53
