Boat Overview

Boat Description

This is the Elan Yachts E3. It's a boat for people who want to go fast and enjoy the ride. It has a sleek design, and it's built with attention to detail. It's built for speed, and it comes with all the bells and whistles you need to make sure that your trip is as comfortable as possible. The Elan Yachts E3 will take you anywhere in style!

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerElan Yachts
Maker websitehttps://www.elan-yachts.com
ModelE3
First built hull2016
VersionDeep draft/Shoal draft
Price245,000 $
Boat typeSail
CategoryCruiser/Racer BoatsDaysailer BoatsHigh Performance BoatsSports Cruiser Boats
Hull typeMonohull
Hull materialMonohull
Cabins2
Births6
Heads1
General
NameValue
Top speed11.52 kmh
Mast height15.91 m
Length overall9.27 m
Length at waterline8.75 m
Beam overall3.26 m
Draft maximum2.16 m
Displacement4,289.62 kg
Ballast weight894.94 kg
HelmTwin helm wheels
RudderTwin rudders
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioHumphreys Yacht Design
Websitehttp://www.humphreysdesign.com
Name/StudioElan Design Team
Rig & Sails
NameValue
Mast52.2
SparsAluminum spars
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area53.61 sq.m
Downwind sail area105.17 sq.m
Mainsail A340.1
Headsail A289.5
Spinnaker A931
Engine
NameValue
Engine A
MakerYanmar
Model3YM20 15.3 kW
Power21 HP
TypeInboard engine ; Diesel
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement21.69
Downwind SA to Displacement42.55
Hull Displacement Speed 0.05
Displacement to Length (D/L) 7.18
Ballast to Displacement (B/D) 0.21
Capsize Screening Formula (CSF) 2.03
