Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerEtap
Maker websitehttps://www.etapyachting.com
ModelEtap 23iL - Lifting Keel
First built hull1995
VersionLifting Keel
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed9.72 kmh
Mast height10.39 m
Length overall7.8 m
Length at waterline6.22 m
Beam overall2.5 m
Draft maximum1.25 m
Displacement1,549.92 kg
Ballast weight469.92 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Unsinkable
Trailerable
Designer
NameValue
Naval architect
Name/StudioJac De Ridder
Rig & Sails
NameValue
Mast34.1
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area28.89 sq.m
Downwind sail area41.43 sq.m
Mainsail A151.00
Spinnaker A295.00
Spinnaker A62.00
Spinnaker A28.00
Engine
NameValue
Engine A
TypeOutboard engine ; Gas
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 10.65
Upwind SA to Displacement21.94
Downwind SA to Displacement31.46
Hull Displacement Speed 6.05
Displacement to Length (D/L) 179.68
Ballast to Displacement (B/D) 30.32
Capsize Screening Formula (CSF) 2.18
