Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.08 m
Specs
Main
| Maker | Etap Yachts |
| Maker website | https://www.etapyachting.com |
| Model | Etap 30 - Deep draft |
| First built hull | 1984 |
| Version | Deep draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.96 kmh |
| Mast height | 13.84 m |
| Length overall | 9.08 m |
| Length at waterline | 7.65 m |
| Beam overall | 3.17 m |
| Beam hull | 1.89 m |
| Draft maximum | 1.56 m |
| Displacement | 4,399.84 kg |
| Ballast weight | 1,324.94 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
| Unsinkable |
Designer
| Naval architect | |
| Name/Studio | Jac De Ridder |
Rig & Sails
| Mast | 45.4 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back |
| Upwind sail area | 51 sq.m |
| Downwind sail area | 79.15 sq.m |
Engine
| Engine A | |
| Power | 18 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 19.32 |
| Downwind SA to Displacement | 29.98 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.71 |
| Ballast to Displacement (B/D) | 0.3 |
| Capsize Screening Formula (CSF) | 1.95 |
