Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.39 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Etap Yachts |
| Maker website | https://www.etapyachting.com |
| Model | Etap 30i - Deep draft |
| First built hull | 1995 |
| Version | Deep draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Top speed | 11.06 kmh |
| Mast height | 13.59 m |
| Length overall | 9.39 m |
| Length at waterline | 7.99 m |
| Beam overall | 3.2 m |
| Headroom | 1.86 m |
| Draft maximum | 1.74 m |
| Displacement | 3,499.92 kg |
| Ballast weight | 1,099.96 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller (EVS: Etap Vertical Steering System in option) |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
| Unsinkable |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Alain Mortain ; Yiannis Mavrikios |
| Website | http://www.mortain-mavrikios.com/ |
Rig & Sails
| Name | Value |
|---|---|
| Mast | 44.6 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back |
| Upwind sail area | 40.6 sq.m |
| Downwind sail area | 71.72 sq.m |
| Mainsail A | 262.00 |
| Spinnaker A | 511.00 |
| Spinnaker A | 137.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 18 HP |
| Type | Inboard Engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 17.91 |
| Downwind SA to Displacement | 31.64 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.86 |
| Ballast to Displacement (B/D) | 0.31 |
| Capsize Screening Formula (CSF) | 2.13 |
