Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11.89 m
Specs
Main
| Maker | Etap Yachts |
| Maker website | https://www.etapyachting.com |
| Model | Etap 39s - Deep Draft |
| First built hull | 1998 |
| Version | Deep Draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.47 kmh |
| Mast height | 17.4 m |
| Length overall | 11.89 m |
| Length at waterline | 10.24 m |
| Beam overall | 3.87 m |
| Draft maximum | 1.98 m |
| Displacement | 6,799.8 kg |
| Ballast weight | 2,049.78 kg |
| Ballast type | Lead |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
| Unsinkable |
Designer
| Naval architect | |
| Name/Studio | J&J Yacht Design |
| Website | https://jnj.design |
Rig & Sails
| Mast | 57.1 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 18 ° |
| Upwind sail area | 77.57 sq.m |
| Downwind sail area | 113.43 sq.m |
Engine
| Engine A | |
| Power | 50 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 21.98 |
| Downwind SA to Displacement | 32.14 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 7.77 |
| Ballast to Displacement (B/D) | 0.3 |
| Capsize Screening Formula (CSF) | 2.06 |
