Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.83 m
Specs
Main
| Maker | RM Yachts |
| Maker website | https://www.rm-yachts.com |
| Model | RM 1180 Fin keel |
| First built hull | 2019 |
| Version | Fin keel |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Mast height | 19.14 m |
| Length overall | 12.83 m |
| Beam overall | 4.39 m |
| Draft maximum | 2.29 m |
| Displacement | 6,999.83 kg |
| Helm | 2 wheels |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Marc Lombard Yacht Design Group |
| Website | http://www.marclombard.com/ |
Rig & Sails
| Mast | 62.8 |
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | Single-strand (ROD) discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 91.97 sq.m |
| Downwind sail area | 196.95 sq.m |
Engine
| Engine A | |
| Power | 50 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 25.56 |
| Downwind SA to Displacement | 54.74 |
| Hull Displacement Speed | 0.07 |
| Capsize Screening Formula (CSF) | 2.32 |
