Name	Value
Maker	RM Yachts
Maker website	https://www.rm-yachts.com
Model	RM 1180 Twin keel
First built hull	2015
Version	Twin keel
Boat type	Sail
Category	Cruiser Boats
Hull type	Catamaran Boats
Hull material	Catamaran Boats

Name	Value
Mast height	19.14 m
Length overall	12.83 m
Beam overall	4.39 m
Draft maximum	1.98 m
Displacement	6,999.83 kg
Helm	2 wheels
Rudder	2 spade rudders
Cockpit	Open aft cockpit

Name	Value
Naval architect
Name/Studio	Marc Lombard Yacht Design Group
Website	http://www.marclombard.com/

Name	Value
Mast	62.8
Spars	Mast and boom in Aluminum (carbon fiber as an option)
Standing rigging	Single-strand (ROD) discontinuous
Number of spreaders	2
Spreaders angle	Swept-back
Upwind sail area	91.97 sq.m
Downwind sail area	196.95 sq.m
Mainsail A	506.00
Spinnaker A	1615.00

Name	Value
Engine A
Power	50 HP
Type	Inboard engine ; Diesel
Engine B

2015 RM Yachts RM 1180 Twin keel

Boat Overview

Type

Maker

Hull type

Hull Material

Fiberglass

Category

Boat length (LOA)

12.83 m

See all details

Overview

Discover the Pro

Specs

Performance & Ratios

Name	Value
Sail Area to Displacement (SA/D)	0.07
Upwind SA to Displacement	25.56
Downwind SA to Displacement	54.74
Hull Displacement Speed	0.07
Capsize Screening Formula (CSF)	2.32
