Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.61 m
Specs
Main
Name | Value |
---|---|
Maker | RM Yachts |
Maker website | https://www.rm-yachts.com |
Model | RM 970 Fin keel |
First built hull | 2013 |
Version | Fin keel |
Price | 120,000 € |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.68 kmh |
Mast height | 16.09 m |
Length overall | 10.61 m |
Length at waterline | 8.99 m |
Beam overall | 3.69 m |
Draft maximum | 1.86 m |
Displacement | 5,150.08 kg |
Ballast weight | 1,235.13 kg |
Helm | 1 tiller (helm wheel in option) |
Rudder | 1 spade rudder (Double as option) |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Marc Lombard Yacht Design Group |
Website | http://www.marclombard.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 52.8 |
Spars | Mast and boom in Aluminum (carbon fiber as an option) |
Standing rigging | 1x19 strand wire discontinuous |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 61.13 sq.m |
Downwind sail area | 128.3 sq.m |
Mainsail A | 358.00 |
Spinnaker A | 1023.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 20 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 20.85 |
Downwind SA to Displacement | 43.76 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 7.28 |
Ballast to Displacement (B/D) | 0.24 |
Capsize Screening Formula (CSF) | 2.16 |
