Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.61 m
Specs
Main
| Maker | RM Yachts |
| Maker website | https://www.rm-yachts.com |
| Model | RM 970 Twin keel |
| First built hull | 2016 |
| Version | Twin keel |
| Price | 120,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.68 kmh |
| Mast height | 16.09 m |
| Length overall | 10.61 m |
| Length at waterline | 8.99 m |
| Beam overall | 3.69 m |
| Draft maximum | 1.68 m |
| Displacement | 5,150.08 kg |
| Ballast weight | 1,290.02 kg |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 spade rudder (Double as option) |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Marc Lombard Yacht Design Group |
| Website | http://www.marclombard.com/ |
Rig & Sails
| Mast | 52.8 |
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 61.13 sq.m |
| Downwind sail area | 128.3 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 20 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 20.85 |
| Downwind SA to Displacement | 43.76 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.28 |
| Ballast to Displacement (B/D) | 0.25 |
| Capsize Screening Formula (CSF) | 2.16 |
