Boat Overview
Type
Maker
Hull type
Hull Material
Aluminium
Category
Boat length (LOA)
9.02 m
Specs
Main
| Maker | Form Ocean |
| Model | Oxion 32 Alu |
| First built hull | 1981 |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Aluminium |
General
| Top speed | 10.7 kmh |
| Length overall | 9.02 m |
| Length at waterline | 7.53 m |
| Beam overall | 3.08 m |
| Beam hull | 1.86 m |
| Draft maximum | 1.89 m |
| Displacement | 4,999.94 kg |
| Ballast weight | 1,700.06 kg |
| Helm | 1 tiller |
| Rudder | 1 rudder on skeg |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 52.95 sq.m |
| Downwind sail area | 87.98 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 20 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 18.42 |
| Downwind SA to Displacement | 30.6 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.66 |
| Ballast to Displacement (B/D) | 0.34 |
| Capsize Screening Formula (CSF) | 1.82 |
