Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.49 m
Specs
Main
| Maker | Gib Sea |
| Model | Gib'Sea 105 - Plus |
| First built hull | 1980 |
| Version | Plus |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.68 kmh |
| Length overall | 10.49 m |
| Length at waterline | 8.99 m |
| Beam overall | 3.38 m |
| Beam hull | 1.86 m |
| Draft maximum | 1.56 m |
| Displacement | 4,599.88 kg |
| Ballast weight | 1,700.06 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 rudder on skeg |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 70.98 sq.m |
| Downwind sail area | 121.52 sq.m |
Engine
| Engine A | |
| Power | 28 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 26.1 |
| Downwind SA to Displacement | 44.68 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.28 |
| Ballast to Displacement (B/D) | 0.37 |
| Capsize Screening Formula (CSF) | 2.05 |
