Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.74 m
Specs
Main
| Maker | Gib Sea |
| Model | Gib'Sea 262 - Deep draft |
| First built hull | 1989 |
| Version | Deep draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.17 kmh |
| Mast height | 11.92 m |
| Length overall | 7.74 m |
| Length at waterline | 6.77 m |
| Beam overall | 2.99 m |
| Beam hull | 1.95 m |
| Draft maximum | 1.25 m |
| Displacement | 3,049.95 kg |
| Ballast weight | 749.79 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 transom hung rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Groupe GRAAL |
Rig & Sails
| Mast | 39.11 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | Swept-back |
| Upwind sail area | 40.51 sq.m |
| Downwind sail area | 71.35 sq.m |
Engine
| Engine A | |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 19.59 |
| Downwind SA to Displacement | 34.5 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.31 |
| Ballast to Displacement (B/D) | 0.25 |
| Capsize Screening Formula (CSF) | 2.08 |
