Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.99 m
Specs
Main
Name | Value |
---|---|
Maker | Gib Sea |
Model | Gib'Sea 264 |
First built hull | 1995 |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.36 kmh |
Mast height | 12.34 m |
Length overall | 7.99 m |
Length at waterline | 7.04 m |
Beam overall | 2.99 m |
Headroom | 1.77 m |
Draft maximum | 2.07 m |
Displacement | 1,900.1 kg |
Ballast weight | 800.14 kg |
Ballast type | Cast iron |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
Name | Value |
---|---|
Mast | 40.5 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 36.51 sq.m |
Mainsail A | 242.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Diesel for inboard engine, Gas for outboard |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 24.2 |
Displacement to Length (D/L) | 6.44 |
Ballast to Displacement (B/D) | 0.42 |
Capsize Screening Formula (CSF) | 2.43 |
