Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.65 m
Specs
Main
Name | Value |
---|---|
Maker | Gib Sea |
Model | Gib'Sea 80 Plus - Fin keel |
First built hull | 1978 |
Version | Fin keel |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 9.59 kmh |
Mast height | 10.36 m |
Length overall | 7.65 m |
Length at waterline | 5.82 m |
Beam overall | 2.5 m |
Headroom | 1.46 m |
Draft maximum | 1.55 m |
Displacement | 1,399.78 kg |
Ballast weight | 449.96 kg |
Ballast type | Cast iron |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Jean Berret |
Website | http://www.berret-racoupeau.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 34 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 30.75 sq.m |
Downwind sail area | 47.47 sq.m |
Mainsail A | 161.00 |
Spinnaker A | 350.00 |
Spinnaker A | 116.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard engine ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 24.99 |
Downwind SA to Displacement | 38.58 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 5.86 |
Ballast to Displacement (B/D) | 0.32 |
Capsize Screening Formula (CSF) | 2.26 |
