Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.44 m
Specs
Main
Name | Value |
---|---|
Maker | Gib Sea |
Model | Gib'sea 84 - Fin keel |
First built hull | 1983 |
Version | Fin keel |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 10.33 kmh |
Length overall | 8.44 m |
Length at waterline | 7.01 m |
Beam overall | 3.05 m |
Headroom | 1.74 m |
Draft maximum | 1.58 m |
Displacement | 2,599.99 kg |
Ballast weight | 899.93 kg |
Ballast type | Cast iron |
Helm | 1 tiller |
Rudder | 1 semi-spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Michel Joubert ; Bernard Nivelt |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 43.76 sq.m |
Downwind sail area | 73.86 sq.m |
Mainsail A | 179.00 |
Spinnaker A | 617.00 |
Spinnaker A | 114.00 |
Spinnaker A | 62.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 18 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 23.54 |
Downwind SA to Displacement | 39.73 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 6.43 |
Ballast to Displacement (B/D) | 0.35 |
Capsize Screening Formula (CSF) | 2.24 |
