Specs

Main
MakerGib Sea
ModelGib'sea 92 - Deep draft
First built hull1985
VersionDeep draft
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed10.85 kmh
Mast height12.86 m
Length overall9.51 m
Length at waterline7.74 m
Beam overall3.23 m
Beam hull1.77 m
Draft maximum1.56 m
Displacement4,590 kg
Ballast weight1,150 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioJacques Fauroux
Websitehttp://www.fauroux.com/
Rig & Sails
Mast42.2
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angle0 °
Upwind sail area52.03 sq.m
Downwind sail area87.51 sq.m
Engine
Engine A
Power18 HP
TypeInboard
Storage
Fuel tank A54.89 liter
Water tank A140.06 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 19.15
Upwind SA to Displacement19.15
Downwind SA to Displacement32.22
Hull Displacement Speed 6.75
Displacement to Length (D/L) 275.67
Ballast to Displacement (B/D) 0.25
Capsize Screening Formula (CSF) 1.96
