Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.09 m
Specs
Main
Name | Value |
---|---|
Maker | Gib Sea |
Model | Gib'Sea 96 - Deep draft |
First built hull | 1983 |
Version | Deep draft |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.23 kmh |
Mast height | 13.84 m |
Length overall | 10.09 m |
Length at waterline | 8.26 m |
Beam overall | 3.08 m |
Headroom | 1.89 m |
Draft maximum | 1.77 m |
Displacement | 5,299.77 kg |
Ballast weight | 1,200.2 kg |
Ballast type | Cast iron |
Helm | 1 tiller (helm wheel in option) |
Rudder | 1 semi-spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Michel Joubert |
Rig & Sails
Name | Value |
---|---|
Mast | 45.4 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | 0 ° |
Upwind sail area | 59.18 sq.m |
Downwind sail area | 97.27 sq.m |
Mainsail A | 240.00 |
Spinnaker A | 807.00 |
Spinnaker A | 174.00 |
Spinnaker A | 70.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 28 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.04 |
Upwind SA to Displacement | 19.8 |
Downwind SA to Displacement | 32.55 |
Hull Displacement Speed | 0.04 |
Displacement to Length (D/L) | 6.98 |
Ballast to Displacement (B/D) | 0.23 |
Capsize Screening Formula (CSF) | 1.78 |
