Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11.73 m
Specs
Main
| Maker | Grand Soleil |
| Maker website | https://www.grandsoleil.net |
| Model | GS 37 - B&C |
| First built hull | 2005 |
| Version | Deep draft |
| Boat type | Sail |
| Category | Cruiser/Racer BoatsDaysailer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
| Cabins | 2 |
| Births | 4 |
| Heads | 1 |
General
| Top speed | 12.23 kmh |
| Mast height | 16.92 m |
| Length overall | 11.73 m |
| Length at waterline | 9.81 m |
| Beam overall | 3.66 m |
| Beam hull | 1.89 m |
| Draft maximum | 2.17 m |
| Displacement | 6,800 kg |
| Ballast weight | 2,050 kg |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Marcelino Botin ; Shaun Carkeek |
| Website | http://www.botinpartners.com/ |
Rig & Sails
| Mast | 55.5 |
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 83.98 sq.m |
| Downwind sail area | 154.03 sq.m |
Engine
| Engine A | |
| Fuel | Diesel |
| Power | 27 HP |
| Type | Inboard |
Storage
| Fuel tank A | 140.06 liter |
| Water tank A | 359.61 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 23.8 |
| Downwind SA to Displacement | 43.65 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.6 |
| Ballast to Displacement (B/D) | 0.3 |
| Capsize Screening Formula (CSF) | 1.95 |
