Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
13.93 m
Specs
Main
| Maker | Grand Soleil |
| Maker website | https://www.grandsoleil.net |
| Model | GS 45 - J&V Shoal draft |
| First built hull | 2004 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 13.53 kmh |
| Length overall | 13.93 m |
| Length at waterline | 12.04 m |
| Beam overall | 4.27 m |
| Beam hull | 1.98 m |
| Draft maximum | 1.98 m |
| Displacement | 9,599.82 kg |
| Ballast weight | 3,099.85 kg |
| Helm | 1 wheel |
| Rudder | Closed aft cockpit |
| Cockpit | 1 spade rudder |
Designer
| Naval architect | |
| Name/Studio | Judel/Vrolijk Design |
| Website | http://www.judel-vrolijk.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Spreaders angle | Swept-back |
| Upwind sail area | 115.01 sq.m |
| Downwind sail area | 192.96 sq.m |
Engine
| Engine A | |
| Power | 55 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 25.9 |
| Downwind SA to Displacement | 43.45 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 8.42 |
| Ballast to Displacement (B/D) | 0.32 |
| Capsize Screening Formula (CSF) | 2.03 |
