Boat Overview

Boat Description

The Hallberg Rassy Yard has specialized in series production of seaworthy and comfortable deep water boats of a quality that not even the classic hand built sailing boats can match. We have found how first class joinery can be accomplished with modern industrial methods, and how the beauty of the classic sailing boat hull can be combined with modern sailing techniques.

This was the concept behind our new boat, the HR 26. Designer Olle Enderlein has chosen to create strength and spaciousness through a relatively beamy
hull. The HR 26 is built with a fin keel, which is integral with the hull. Thus the cast iron ballast is incapsuled in the keel, a construction that has proved superior in giving a fin keel the required robustness.

The transom hung rudder results in the best possible efficiency and at the same time the tiller does not encroach on the space in the cockpit. The precisely calculated seating height in the cockpit does not only give you effective protection, but it also affords you safety due to the good visibility forward.

Characteristic of all Hallberg Rassy boats is the flawless joinery, in which every single detail is a combination of utility and beauty. The whole of the interior trim is light and inviting.
The galley is extremely well equipped and includes a propane gas or paraffin stove, whichever you prefer, a built-in ice box, sink, foot-operated fresh water pump and rack for crockery. The fresh water tank contains 65 litres, and the headroom in the galley is the whole of 6 feet.

The stable table has three positions full width in harbour, half width with rails at sea and completely folded when the bunks are used. The HR 26 has four berths, each of which is at least 2 metres long and 70 centimetres wide at shoulder height. The toilet space has also been ergo-metrically designed There is plenty of stowage space and a separate wardrobe. The hardened glass windows in anodized aluminium frames are located at a level giving you a good view of the life going on around you in harbour, a feature that contributes greatly to the pleasure you can enjoy on board the HR 26. A protective rubbing strake runs right around the whole of the hull - a valuable feature in busy harbours at the height of the season.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerHallberg - Rassy
Maker websitehttps://www.hallberg-rassy.com
Model26
First built hull1978
Price17,391 £
Boat typeSail
CategoryCruiser BoatsMotorsailer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Mast height12.04 m
Length overall7.96 m
Beam overall2.47 m
Headroom1.58 m
Draft maximum1.43 m
Displacement2,500.2 kg
Ballast weight1,099.96 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 transom hung rudder
CockpitAft cockpit
Designer
NameValue
Naval architect
Name/StudioOlle Enderlein
Rig & Sails
NameValue
Mast39.5
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area37.16 sq.m
Downwind sail area60.57 sq.m
Mainsail A177
Headsail A224
Headsail B167
Spinnaker A476
Spinnaker A56
Engine
NameValue
Engine A
FuelDiesel
MakerVolvo Penta
ModelMD 5A
Power7.5 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.04
Upwind SA to Displacement20.52
Downwind SA to Displacement33.44
Hull Displacement Speed 0.04
Ballast to Displacement (B/D) 0.44
Capsize Screening Formula (CSF) 1.84
