Boat Description

The Hallberg-Rassy 46 was built in 132 units between 1995 and 2005. Production numbers were shared between the 45 and the 46, although there were different moulds. Hull numbers 1-69 plus Number 83 are Hallberg-Rassy 45s, and 70-202, except No 83, were Hallberg-Rassy 46s.

The Hallberg-Rassy 46 is based on the 45 but extensively upgraded. There are new plugs and moulds for both hull and deck. The hull of the 46  is 44 cm wider at the transom, fading out to zero at the widest point. The freeboard is 10 cm higher at the transom, fading out to zero at the stem. This gives more space below decks. The cockpit is upgraded on the 46, with more seating space, eventhough the length is the same. The 46 has a rubbing strake below the blue stripe on the hull, which is not the case with the 45. The genoa sheet system, the portlights, the windshileld and the aft deck lockers were improved. The number of opening portlights were upgraded from 8 to 13. The 46 was offered both with a deep draft and a shallow draft keel version, the 45 was only built with the shallow draft. The rudder design was renewed on the 46, and the steering system was upgraded from wire to rod links with cardan connection and progressive purchase. The steering pedestal top was improved on the 46, allowing space for more buttons and displays.

Also the interior layout is improved on the 46, particularly visible in the galley and the new forward layout with heads with separate hsower to sb, twin bunks cabin to port side and a separate passage to the v cabin in front, without having to walk through another cabin for access. The headroom in the saloon is improved from 1.94 to 1.98 m, the walk though to the aft cabin increased in headroom from 1.91 to 1.94, at the same it got 8 cm wider, the aft cabin headroom increased from 1.82 to 1.88, the aft heads from 1.76 to 1.91, the aft shower from 1.81 to 1.87 m.

Short-handed sailing is easy in this attractive Frers-designed cruiser. She is both a fairly good performer and seakindly. It is a boat made to go around the world or cruise local waters.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerHallberg - Rassy
Maker websitehttps://www.hallberg-rassy.com
Model46
First built hull1995
Last built hull2005
Price381,329 $
Boat typeSail
CategoryCruiser BoatsMotorsailer BoatsDaysailer BoatsCenter Cockpit BoatsCenter Console Boats
Hull typeMonohull
Hull materialMonohull
Cabins3
Births6
Heads2
General
NameValue
Top speed13.47 kmh
Length overall14.81 m
Length at waterline11.89 m
Beam overall4.39 m
Headroom1.95 m
Draft maximum1.89 m
Displacement16,499.86 kg
Ballast weight6,600.22 kg
Ballast typeLead
Helm1 wheel
Rudder1 spade rudder
CockpitCentral cockpit
Designer
NameValue
Naval architect
Name/StudioFrers Naval Architecture & Engineering
Websitehttp://www.germanfrers.com
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Number of spreaders2
Spreaders angle0 °
Upwind sail area112.04 sq.m
Mainsail A538
Headsail A667
Headsail B538
Engine
NameValue
Engine A
FuelDiesel
MakerVolvo Penta
ModelTAMD31S
Power100 HP
TypeInboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 7.84
Upwind SA to Displacement17.58
Hull Displacement Speed 8.37
Displacement to Length (D/L) 273.76
Ballast to Displacement (B/D) 40
Capsize Screening Formula (CSF) 1.74
