Boat Overview

Boat Description

The P 28, designed by Harry Hallberg, was built during nineteen years 1955 - 1973 up to construction number 536. Nineteen years of production is the longest production span in the yard's history. The P 28 has been built in many different versions. In the beginning all hulls and superstructures were built in mahogany and had fractional rigging. At the end of the 50s a masthead rig replaced the fractional rig and the design of the main window was improved to two individual portlights. As early as 1963 the revolutionary GRP hull was introduced. At the same time the hull was made a bit wider. During an overlapping period 1963-1966 there was a choice between wooden hull and GRP hull.

In 1972 the transom was developed adding on her length from 8.61 m / 28' 3'' to 9.04 m / 29' 8''. The deck was from 1972 covered with teak as a standard and the toerail was made in teak in stead of mahogany. The biggest markets for the P 28 were USA and Sweden. Most of the first 100 boats were sold to the USA. The P 28 is today an icon for the start of Swedish boat building pride.

A P 28 is part of the movie "The way we were", with Barbra Streisand and Robert Redford, recorded 1973, but the action in the movie should show the era between the end of the 1930s and the beginning of the 1950s. So actually some years ahead of when the first P28 was launched.

Classic P 28 "Orion" from the mid 1960s has won the prestigious regatta "Regata Illes Balears Classics" in Palma for the second year in a row 2018 in the class "IR Classics".

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerHallberg - Rassy
Maker websitehttps://www.hallberg-rassy.com
ModelP-28
First built hull1955
Price25,109 $
Boat typeSail
CategoryCruiser BoatsMotorsailer BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins1
Births4
General
NameValue
Top speed9.99 kmh
Length overall8.6 m
Length at waterline6.58 m
Beam overall2.38 m
Headroom1.56 m
Draft maximum1.28 m
Displacement3,100.3 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 rudder on skeg
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioHarry Hallberg
Rig & Sails
NameValue
SparsSpruce or Oregon pine
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area39.48 sq.m
Downwind sail area66.33 sq.m
Mainsail A230
Headsail A105
Headsail B195
Spinnaker A484
Engine
NameValue
Engine A
FuelDiesel
MakerVolvo Penta
ModelMD 1 B
Power10 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.04
Upwind SA to Displacement33.71
Downwind SA to Displacement56.63
Hull Displacement Speed 0.04
Displacement to Length (D/L) 6.23
Capsize Screening Formula (CSF) 1.65
