Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
12.1 m
Discover the Pro
Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!
Try Pro for FreeSpecs
Main
Name | Value |
---|---|
Maker | Hanse Yachts |
Maker website | https://www.hanseyachtsag.com |
Model | 400 |
First built hull | 2006 |
Version | Standard |
Price | 178,969 $ |
Boat type | Sail |
Category | Daysailer BoatsHigh Performance BoatsMotorsailer Boats |
Hull type | Monohull |
Hull material | Monohull |
Cabins | 3 |
Births | 8 |
Heads | 2 |
General
Name | Value |
---|---|
Top speed | 12.84 kmh |
Mast height | 19.51 m |
Length overall | 12.1 m |
Length at waterline | 10.82 m |
Beam overall | 4.05 m |
Headroom | 1.89 m |
Draft maximum | 2.07 m |
Displacement | 8,400.07 kg |
Ballast weight | 2,684.81 kg |
Ballast type | Cast iron |
Helm | Single helm wheel |
Rudder | Single spade rudder |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Judel/Vrolijk Design |
Website | http://www.judel-vrolijk.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 64 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 105.63 sq.m |
Downwind sail area | 172.24 sq.m |
Mainsail A | 562 |
Headsail A | 390 |
Headsail B | 575 |
Spinnaker A | 1292 |
Engine
Name | Value |
---|---|
Engine A | |
Fuel | Diesel |
Power | 27.9 HP |
Type | Inboard |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 26 |
Downwind SA to Displacement | 42.4 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 7.98 |
Ballast to Displacement (B/D) | 0.32 |
Capsize Screening Formula (CSF) | 2.01 |
