2014 Hanse Yachts 505

1439

Report error

Boat Overview

Type
Sail
Maker
Hanse Yachts
Hull type
Monohull
Hull Material
Fiberglass
Category
Motorsailer Boats
Daysailer Boats
Boat length (LOA)
15.3 m
See all details

Boat Description

A new level. Sailing and comfort. The Hanse 505.

Revel in design components for stress-free distance-making with the HANSE 505. Its elegant hull with a long waterline, performance-centred sail plan and comfortable, safe cockpit area ensure a new level of joy in sailing.

Overview

Specs

Hide empty fields

Main

Maker	Hanse Yachts
Maker website	https://www.hanseyachtsag.com
Model	505
First built hull	2014
Version	Standard
Price	264,000 €
Boat type	Sail
Category	Motorsailer Boats Daysailer Boats
Hull type	Monohull
Hull material	Fiberglass
Cabins	5
Births	11
Heads	3

General

Top speed	14.37 kmh
Mast height	22.13 m
Length overall	15.3 m
Length at waterline	13.47 m
Beam overall	4.79 m
Draft maximum	2.16 m
Displacement	14,900.04 kg
Ballast weight	3,999.77 kg
Helm	Twin helm wheels
Rudder	Single spade rudder
Cockpit	Closing aft cockpit with opening system
CE classification A	12

Designer

Naval architect
Name/Studio	Judel/Vrolijk Design
Website	http://www.judel-vrolijk.com/
Interior designer
Name/Studio	Hanse Yachts Design
Website	https://www.hanseyachtsag.com

Rig & Sails

Mast	72.6
Spars	Aluminum spars
Standing rigging	1x19 strand wire
Number of spreaders	2
Spreaders angle	Swept-back
Upwind sail area	119.01 sq.m

Engine

Engine A
Fuel	Diesel
Power	75 HP
Type	inboard

Storage

Performance & Ratios

Hide empty fields

Detail

Upwind SA to Displacement	20.84
Displacement to Length (D/L)	8.91
Ballast to Displacement (B/D)	0.27
Capsize Screening Formula (CSF)	1.96
