Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.09 m
Specs
Main
Name | Value |
---|---|
Maker | Hobie Cat |
Maker website | https://www.hobiecat.com |
Model | Hobie 33 |
First built hull | 1982 |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.97 kmh |
Length overall | 10.09 m |
Length at waterline | 9.17 m |
Beam overall | 2.17 m |
Draft maximum | 1.71 m |
Displacement | 1,901 kg |
Ballast weight | 863.19 kg |
Ballast type | Lead |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Hobbart (Hobie) Alter |
Website | http://www.hobiecat.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | Continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 39.48 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Power | 10 HP |
Type | Outboard Engine ; Gas |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 26.17 |
Displacement to Length (D/L) | 7.35 |
Ballast to Displacement (B/D) | 0.45 |
Capsize Screening Formula (CSF) | 1.77 |
