Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
5.18 m
Specs
Main
Name | Value |
---|---|
Maker | Hobie Cat |
Maker website | https://www.hobiecat.com |
Model | Hobie Cat 17 SE |
First built hull | 1985 |
Version | SE |
Boat type | Sail |
Category | Catamaran Boats |
Hull type | Catamaran Boats |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 5.18 m |
Length at waterline | 5.12 m |
Beam overall | 2.44 m |
Displacement | 154.22 kg |
Helm | 1 tiller |
Rudder | 2 transom hung rudders |
Cockpit | No cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Hobie Cat ; John Wake |
Website | http://www.hobiecat.com/ |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Upwind sail area | 15.61 sq.m |
Downwind sail area | 34.19 sq.m |
Mainsail A | 168.00 |
Spinnaker A | 200.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.15 |
Upwind SA to Displacement | 55.19 |
Downwind SA to Displacement | 120.88 |
Hull Displacement Speed | 0.15 |
Displacement to Length (D/L) | 5.49 |
Capsize Screening Formula (CSF) | 4.59 |
