Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
4.91 m
Specs
Main
Name | Value |
---|---|
Maker | Hobie Cat |
Maker website | https://www.hobiecat.com |
Model | Hobie Cat Max Race |
First built hull | 2003 |
Version | Race |
Price | 10,600 € |
Boat type | Sail |
Category | Catamaran Boats |
Hull type | Catamaran Boats |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 4.91 m |
Length at waterline | 4.61 m |
Beam overall | 2.5 m |
Displacement | 145.15 kg |
Helm | 1 tiller |
Rudder | 2 transom hung rudders |
Cockpit | No cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Hobie Cat Europe |
Website | http://www.hobie-cat.net/ |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back (diamond) |
Upwind sail area | 16.35 sq.m |
Downwind sail area | 31.31 sq.m |
Mainsail A | 137.00 |
Mainsail B | 39.00 |
Spinnaker A | 200.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.14 |
Upwind SA to Displacement | 60.2 |
Downwind SA to Displacement | 115.26 |
Hull Displacement Speed | 0.14 |
Displacement to Length (D/L) | 5.21 |
Capsize Screening Formula (CSF) | 4.8 |
