Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
6 m
Specs
Main
Name | Value |
---|---|
Maker | Hobie Cat |
Maker website | https://www.hobiecat.com |
Model | Hobie Cat Miracle 20 |
First built hull | 1991 |
Boat type | Sail |
Category | Catamaran Boats |
Hull type | Catamaran Boats |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Length overall | 6 m |
Length at waterline | 5.73 m |
Beam overall | 2.62 m |
Displacement | 190.96 kg |
Helm | 1 tiller |
Rudder | 2 transom hung rudders |
Cockpit | No cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Hobie Cat ; Jack Groeneveld |
Rig & Sails
Name | Value |
---|---|
Rotating spars | |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back (diamond) |
Upwind sail area | 23.23 sq.m |
Downwind sail area | 39.11 sq.m |
Mainsail A | 195.00 |
Mainsail B | 55.00 |
Spinnaker A | 226.00 |
Engine
Name | Value |
---|---|
Engine A | |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.14 |
Upwind SA to Displacement | 71.22 |
Downwind SA to Displacement | 119.93 |
Hull Displacement Speed | 0.14 |
Displacement to Length (D/L) | 5.81 |
Capsize Screening Formula (CSF) | 4.59 |
