Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.49 m
Specs
Main
| Maker | Idb Marine |
| Maker website | https://www.idbmarine.com |
| Model | Malango 1045 Swing keel |
| First built hull | 2013 |
| Version | Swing keel |
| Price | 133,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.54 kmh |
| Length overall | 10.49 m |
| Length at waterline | 10.09 m |
| Beam overall | 3.69 m |
| Draft maximum | 2.47 m |
| Displacement | 3,360.21 kg |
| Ballast weight | 1,299.99 kg |
| Ballast type | Cast iron |
| Helm | 2 tillers |
| Rudder | 2 spade rudders |
| Cockpit | Closed aft cockpit |
| Unsinkable |
Designer
| Naval architect | |
| Name/Studio | Julien Marin |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 62.99 sq.m |
| Downwind sail area | 133.04 sq.m |
Engine
| Engine A | |
| Power | 20 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 28.56 |
| Downwind SA to Displacement | 60.31 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.71 |
| Ballast to Displacement (B/D) | 0.39 |
| Capsize Screening Formula (CSF) | 2.49 |
