Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11 m
Specs
Main
| Maker | Idb Marine |
| Maker website | https://www.idbmarine.com |
| Model | Malango 1088 Swing keel |
| First built hull | 2017 |
| Version | Swing keel |
| Price | 162,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.89 kmh |
| Length overall | 11 m |
| Length at waterline | 10.7 m |
| Beam overall | 3.99 m |
| Draft maximum | 2.8 m |
| Displacement | 4,000 kg |
| Ballast weight | 1,500 kg |
| Ballast type | Cast iron |
| Helm | 2 tillers |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Pierre Rolland |
| Website | http://www.rolland-archi.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire discontinuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 74.04 sq.m |
| Downwind sail area | 150.97 sq.m |
Engine
| Engine A | |
| Power | 28 HP |
| Type | Inboard |
Storage
| Fuel tank A | 60.19 liter |
| Water tank A | 369.83 liter |
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 29.89 |
| Downwind SA to Displacement | 60.94 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.94 |
| Ballast to Displacement (B/D) | 0.38 |
| Capsize Screening Formula (CSF) | 2.54 |
