Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
15.91 m
Specs
Main
Name | Value |
---|---|
Maker | Island Packet Yachts |
Maker website | https://www.ipy.com |
Model | Island Packet 525 |
First built hull | 2015 |
Price | 665,000 € |
Boat type | Sail |
Category | Cruiser BoatsCenter Cockpit Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Mast height | 19.39 m |
Length overall | 15.91 m |
Length at waterline | 13.14 m |
Beam overall | 4.69 m |
Headroom | 1.98 m |
Draft maximum | 1.58 m |
Displacement | 19,999.78 kg |
Ballast weight | 7,250.21 kg |
Ballast type | Lead |
Helm | 1 wheel |
Rudder | 1 rudder on skeg |
Cockpit | Central cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Robert Johnson |
Rig & Sails
Name | Value |
---|---|
Mast | 63.6 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 2 |
Spreaders angle | 0 ° |
Upwind sail area | 114.64 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Power | 110 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 15.83 |
Displacement to Length (D/L) | 8.8 |
Ballast to Displacement (B/D) | 0.36 |
Capsize Screening Formula (CSF) | 1.75 |
