2015 J Boats J/112e

1706

Report error

2015 J Boats J/112e
2015 J Boats J/112e
2015 J Boats J/112e
2015 J Boats J/112e
2015 J Boats J/112e
2015 J Boats J/112e
Preview
2015 J Boats J/112e
Preview
2015 J Boats J/112e
Preview
2015 J Boats J/112e
Preview
2015 J Boats J/112e
Preview

Boat Overview

Specs

Main
NameValue
MakerJ Boats
Maker websitehttps://www.jboats.com
ModelJ/112e
First built hull2015
Price176,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
NameValue
Top speed12.15 kmh
Mast height17.1 m
Length overall11 m
Length at waterline9.48 m
Beam overall3.38 m
Draft maximum1.86 m
Displacement5,125.14 kg
Ballast typeCast iron fin with lead bulb
Helm1 wheel
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioAlan Johnstone
Websitehttp://www.jboats.com/
Rig & Sails
NameValue
Mast56.1
SparsMast and boom in Aluminum
Standing riggingSingle-strand (ROD)
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area70.98 sq.m
Downwind sail area157.01 sq.m
Mainsail A398.00
Spinnaker A1292.00
Engine
NameValue
Engine A
Power30 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.06
Upwind SA to Displacement24.28
Downwind SA to Displacement53.72
Hull Displacement Speed 0.06
Displacement to Length (D/L) 7.47
Capsize Screening Formula (CSF) 1.98
