Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.7 m
Specs
Main
| Maker | J Boats |
| Maker website | https://www.jboats.com |
| Model | J/11S |
| First built hull | 2016 |
| Price | 165,000 € |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.38 kmh |
| Length overall | 10.7 m |
| Length at waterline | 9.78 m |
| Beam overall | 3.08 m |
| Draft maximum | 2.19 m |
| Displacement | 4,599.88 kg |
| Ballast weight | 1,569.88 kg |
| Helm | 1 tiller |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Alan Johnstone |
| Website | http://www.jboats.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Dyform |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 62.99 sq.m |
| Downwind sail area | 95.04 sq.m |
Engine
| Engine A | |
| Power | 18 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 23.16 |
| Downwind SA to Displacement | 34.95 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 7.59 |
| Ballast to Displacement (B/D) | 0.34 |
| Capsize Screening Formula (CSF) | 1.87 |
