Specs

Main
MakerJ Boats
Maker websitehttps://www.jboats.com
ModelJ/130
First built hull1994
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialComposite_Material
General
Top speed13.33 kmh
Length overall12.83 m
Length at waterline11.64 m
Beam overall3.69 m
Draft maximum2.62 m
Displacement7,711 kg
Ballast weight2,880 kg
Helm1 wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioRod Johnstone
Websitehttp://www.jboats.com/
Rig & Sails
SparsMast and boom in Aluminum
Number of spreaders3
Spreaders angleSwept-back
Upwind sail area88.82 sq.m
Engine
Engine A
Power47 HP
TypeInboard
Storage
Water tank A230.15 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 23.14
Upwind SA to Displacement23.14
Hull Displacement Speed 8.28
Displacement to Length (D/L) 136.15
Ballast to Displacement (B/D) 0.37
Capsize Screening Formula (CSF) 1.88
