Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerJ Boats
Maker websitehttps://www.jboats.com
ModelJ/133
First built hull2004
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed13.26 kmh
Length overall13.11 m
Length at waterline11.31 m
Beam overall3.69 m
Draft maximum2.32 m
Displacement8,099.79 kg
Ballast weight3,299.88 kg
Ballast typeLead
Helm1 wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioRod Johnstone
Websitehttp://www.jboats.com/
Rig & Sails
NameValue
SparsMast in Carbon fiber and boom in Aluminum
Standing riggingSingle-strand (ROD)
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area115.76 sq.m
Downwind sail area188.13 sq.m
Mainsail A582.00
Spinnaker A1442.00
Engine
NameValue
Engine A
Power59 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.06
Upwind SA to Displacement29.19
Downwind SA to Displacement47.44
Hull Displacement Speed 0.06
Displacement to Length (D/L) 8.16
Ballast to Displacement (B/D) 0.41
Capsize Screening Formula (CSF) 1.85
