Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
16.09 m
Specs
Main
Name | Value |
---|---|
Maker | J Boats |
Maker website | https://www.jboats.com |
Model | J/160 Standard |
First built hull | 1995 |
Version | Standard |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 14.87 kmh |
Mast height | 21.95 m |
Length overall | 16.09 m |
Length at waterline | 14.51 m |
Beam overall | 4.45 m |
Headroom | 1.95 m |
Draft maximum | 2.19 m |
Displacement | 14,599.77 kg |
Ballast weight | 5,449.91 kg |
Helm | 1 wheel |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Rod Johnstone |
Website | http://www.jboats.com/ |
Rig & Sails
Name | Value |
---|---|
Mast | 72 |
Spars | Mast in Carbon fiber and boom in Aluminum |
Upwind sail area | 127.74 sq.m |
Engine
Name | Value |
---|---|
Engine A | |
Power | 88 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Upwind SA to Displacement | 21.75 |
Displacement to Length (D/L) | 9.25 |
Ballast to Displacement (B/D) | 0.37 |
Capsize Screening Formula (CSF) | 1.84 |
