Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
7.32 m
Specs
Main
Name | Value |
---|---|
Maker | J Boats |
Maker website | https://www.jboats.com |
Model | J/24 |
First built hull | 1977 |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 9.64 kmh |
Length overall | 7.32 m |
Length at waterline | 6.1 m |
Beam overall | 2.47 m |
Draft maximum | 0.95 m |
Displacement | 1,399.78 kg |
Ballast weight | 430.01 kg |
Ballast type | Lead |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Closed aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Rod Johnstone |
Website | http://www.jboats.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 32.24 sq.m |
Downwind sail area | 52.21 sq.m |
Mainsail A | 153.00 |
Spinnaker A | 409.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard Engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 26.2 |
Downwind SA to Displacement | 42.43 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 5.99 |
Ballast to Displacement (B/D) | 0.31 |
Capsize Screening Formula (CSF) | 2.23 |
