Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.9 m
Specs
Main
Name | Value |
---|---|
Maker | J Boats |
Maker website | https://www.jboats.com |
Model | J/88 |
First built hull | 2013 |
Price | 88,000 € |
Boat type | Sail |
Category | Cruiser/Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.17 kmh |
Length overall | 8.9 m |
Length at waterline | 7.96 m |
Beam overall | 2.93 m |
Draft maximum | 2.01 m |
Displacement | 2,249.82 kg |
Ballast weight | 850.03 kg |
Helm | 1 tiller |
Rudder | 1 rudder on ama with T-foil |
Cockpit | Open aft cockpit |
Trailerable |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Alan Johnstone |
Website | http://www.jboats.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast in Carbon fiber and boom in Aluminum |
Standing rigging | Dyform |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 47.47 sq.m |
Downwind sail area | 122.54 sq.m |
Mainsail A | 296.00 |
Spinnaker A | 1023.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 14 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.09 |
Upwind SA to Displacement | 28.12 |
Downwind SA to Displacement | 72.58 |
Hull Displacement Speed | 0.09 |
Displacement to Length (D/L) | 6.85 |
Ballast to Displacement (B/D) | 0.38 |
Capsize Screening Formula (CSF) | 2.25 |
