Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
8.87 m
Specs
Main
| Maker | J Boats |
| Maker website | https://www.jboats.com |
| Model | J/92s |
| First built hull | 2005 |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.09 kmh |
| Mast height | 14.05 m |
| Length overall | 8.87 m |
| Length at waterline | 8.11 m |
| Beam overall | 3.05 m |
| Beam hull | 1.25 m |
| Draft maximum | 1.89 m |
| Displacement | 2,550.09 kg |
| Ballast weight | 1,050.07 kg |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Rod Johnstone |
| Website | http://www.jboats.com/ |
Rig & Sails
| Mast | 46.1 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | Dyform |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 57.51 sq.m |
| Downwind sail area | 117.99 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 19 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.08 |
| Upwind SA to Displacement | 31.33 |
| Downwind SA to Displacement | 64.29 |
| Hull Displacement Speed | 0.08 |
| Displacement to Length (D/L) | 6.91 |
| Ballast to Displacement (B/D) | 0.41 |
| Capsize Screening Formula (CSF) | 2.25 |
