Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.69 m
Specs
Main
| Maker | J Boats |
| Maker website | https://www.jboats.com |
| Model | J/97e |
| First built hull | 2009 |
| Price | 117,000 € |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.12 kmh |
| Length overall | 9.69 m |
| Length at waterline | 8.14 m |
| Beam overall | 3.35 m |
| Beam hull | 1.83 m |
| Draft maximum | 1.89 m |
| Displacement | 3,899.98 kg |
| Ballast weight | 1,344.9 kg |
| Ballast type | Cast iron fin with lead bulb |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Rod Johnstone |
| Website | http://www.jboats.com/ |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | Dyform |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 52.4 sq.m |
| Downwind sail area | 129.97 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 14 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 21.51 |
| Downwind SA to Displacement | 53.35 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 6.92 |
| Ballast to Displacement (B/D) | 0.34 |
| Capsize Screening Formula (CSF) | 2.15 |
