Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerJ Boats
Maker websitehttps://www.jboats.com
ModelJ/99
First built hull2019
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed11.54 kmh
Length overall9.97 m
Length at waterline8.75 m
Beam overall3.41 m
Draft maximum2.04 m
Displacement3,800.19 kg
Ballast weight1,519.99 kg
Ballast typeCast iron fin with lead bulb
Helm1 tiller
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioAlan Johnstone
Websitehttp://www.jboats.com/
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing riggingDyform discontinuous
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area59.18 sq.m
Downwind sail area132.02 sq.m
Mainsail A334.00
Spinnaker A969.00
Spinnaker A1087.00
Engine
NameValue
Engine A
Power18 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.07
Upwind SA to Displacement24.72
Downwind SA to Displacement55.14
Hull Displacement Speed 0.07
Displacement to Length (D/L) 7.18
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 2.21
