Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.78 m
Specs
Main
| Maker | JPK |
| Maker website | https://www.jpk.fr |
| Model | JPK 1010 Fin keel |
| First built hull | 2010 |
| Version | Fin keel |
| Price | 102,000 € |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.56 kmh |
| Length overall | 9.78 m |
| Length at waterline | 8.78 m |
| Beam overall | 3.38 m |
| Beam hull | 1.89 m |
| Draft maximum | 2.01 m |
| Displacement | 3,850.09 kg |
| Ballast weight | 1,650.17 kg |
| Ballast type | Cast iron / lead fin |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Jacques Valer |
Rig & Sails
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 57.97 sq.m |
| Downwind sail area | 128.02 sq.m |
Engine
| Engine A | |
| Power | 18 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 24 |
| Downwind SA to Displacement | 53 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 7.19 |
| Ballast to Displacement (B/D) | 0.43 |
| Capsize Screening Formula (CSF) | 2.18 |
