Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
10.09 m
Specs
Main
| Maker | JPK |
| Maker website | https://www.jpk.fr |
| Model | JPK 1030 |
| First built hull | 2019 |
| Price | 113,000 € |
| Boat type | Sail |
| Category | Racer Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 11.76 kmh |
| Length overall | 10.09 m |
| Length at waterline | 9.08 m |
| Beam overall | 3.26 m |
| Beam hull | 1.86 m |
| Draft maximum | 2.01 m |
| Displacement | 3,600.16 kg |
| Ballast weight | 1,500.03 kg |
| Ballast type | Cast iron / lead fin |
| Helm | 1 tiller |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Jacques Valer |
Rig & Sails
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 61.04 sq.m |
| Downwind sail area | 140.01 sq.m |
Engine
| Engine A | |
| Power | 18 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 26.43 |
| Downwind SA to Displacement | 60.62 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.31 |
| Ballast to Displacement (B/D) | 0.42 |
| Capsize Screening Formula (CSF) | 2.15 |
