Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.82 m
Specs
Main
| Name | Value |
|---|---|
| Maker | JPK |
| Maker website | https://www.jpk.fr |
| Model | JPK 10.80 |
| First built hull | 2014 |
| Price | 141,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Name | Value |
|---|---|
| Top speed | 11.97 kmh |
| Length overall | 10.82 m |
| Length at waterline | 9.17 m |
| Beam overall | 3.38 m |
| Headroom | 1.95 m |
| Draft maximum | 2.19 m |
| Displacement | 4,849.81 kg |
| Ballast weight | 2,150.03 kg |
| Helm | 1 tiller |
| Rudder | 1 spade rudder |
| Cockpit | Open aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Jacques Valer |
Rig & Sails
| Name | Value |
|---|---|
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 73.02 sq.m |
| Downwind sail area | 159.98 sq.m |
| Mainsail A | 431.00 |
| Spinnaker A | 1292.00 |
| Spinnaker A | 1130.00 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Power | 18 HP |
| Type | Inboard engine ; Diesel |
| Engine B |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 25.92 |
| Downwind SA to Displacement | 56.79 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.35 |
| Ballast to Displacement (B/D) | 0.44 |
| Capsize Screening Formula (CSF) | 2.02 |
