Name	Value
Maker	JPK
Maker website	https://www.jpk.fr
Model	JPK 38 Fast Cruiser Swing keel
First built hull	2012
Version	Swing keel
Price	180,000 €
Boat type	Sail
Category	Cruiser Boats
Hull type	Monohull
Hull material	Monohull

Name	Value
Top speed	12.6 kmh
Length overall	11.4 m
Length at waterline	10.39 m
Beam overall	3.99 m
Draft maximum	2.47 m
Displacement	5,400.01 kg
Ballast weight	1,900.1 kg
Ballast type	Glass fiber/vinylester (infusion) fin with lead bulb
Helm	2 tillers
Rudder	2 spade rudders
Cockpit	Open aft cockpit

Name	Value
Naval architect
Name/Studio	Jacques Valer

Name	Value
Spars	Mast and boom in Aluminum (carbon fiber as an option)
Standing rigging	1x19 strand wire
Number of spreaders	2
Spreaders angle	Swept-back
Upwind sail area	74.04 sq.m
Downwind sail area	170.01 sq.m
Mainsail A	431.00
Spinnaker A	1399.00
Spinnaker A	269.00

Name	Value
Engine A
Power	40 HP
Type	Inboard engine ; Diesel
Engine B

2012 JPK JPK 38 Fast Cruiser Swing keel

Boat Overview

Type

Maker

Hull type

Hull Material

Fiberglass

Category

Boat length (LOA)

11.4 m

See all details

Overview

Discover the Pro

Specs

Performance & Ratios

Name	Value
Sail Area to Displacement (SA/D)	0.07
Upwind SA to Displacement	24.47
Downwind SA to Displacement	56.18
Hull Displacement Speed	0.07
Displacement to Length (D/L)	7.82
Ballast to Displacement (B/D)	0.35
Capsize Screening Formula (CSF)	2.3
