Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11.4 m
Specs
Main
| Maker | JPK |
| Maker website | https://www.jpk.fr |
| Model | JPK 38 Fast Cruiser Swing keel |
| First built hull | 2012 |
| Version | Swing keel |
| Price | 180,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.6 kmh |
| Length overall | 11.4 m |
| Length at waterline | 10.39 m |
| Beam overall | 3.99 m |
| Draft maximum | 2.47 m |
| Displacement | 5,400.01 kg |
| Ballast weight | 1,900.1 kg |
| Ballast type | Glass fiber/vinylester (infusion) fin with lead bulb |
| Helm | 2 tillers |
| Rudder | 2 spade rudders |
| Cockpit | Open aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Jacques Valer |
Rig & Sails
| Spars | Mast and boom in Aluminum (carbon fiber as an option) |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | Swept-back |
| Upwind sail area | 74.04 sq.m |
| Downwind sail area | 170.01 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 40 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.07 |
| Upwind SA to Displacement | 24.47 |
| Downwind SA to Displacement | 56.18 |
| Hull Displacement Speed | 0.07 |
| Displacement to Length (D/L) | 7.82 |
| Ballast to Displacement (B/D) | 0.35 |
| Capsize Screening Formula (CSF) | 2.3 |
