2016 JPK JPK 45 Fin keel

1910

Report error

2016 JPK JPK 45 Fin keel
2016 JPK JPK 45 Fin keel
2016 JPK JPK 45 Fin keel
2016 JPK JPK 45 Fin keel
2016 JPK JPK 45 Fin keel
Preview
2016 JPK JPK 45 Fin keel
Preview
2016 JPK JPK 45 Fin keel
Preview
2016 JPK JPK 45 Fin keel
Preview

Boat Overview

Specs

Main
NameValue
MakerJPK
Maker websitehttps://www.jpk.fr
ModelJPK 45 Fin keel
First built hull2016
VersionFin keel
Price315,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
General
NameValue
Length overall13.84 m
Beam overall4.3 m
Draft maximum2.19 m
Displacement9,500.03 kg
Ballast weight3,999.77 kg
Ballast typeCast iron fin with lead bulb
Helm2 wheels
Rudder2 spade rudders
CockpitOpen aft cockpit
Designer
NameValue
Naval architect
Name/StudioJacques Valer
Rig & Sails
NameValue
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingDyform
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area112.97 sq.m
Downwind sail area257.99 sq.m
Mainsail A570.00
Spinnaker A2207.00
Spinnaker A1292.00
Engine
NameValue
Engine A
Power65 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.07
Upwind SA to Displacement25.62
Downwind SA to Displacement58.5
Hull Displacement Speed 0.07
Ballast to Displacement (B/D) 0.42
Capsize Screening Formula (CSF) 2.05
